MECHANICAL

Engine, Vortec 6.0L V8 (342 hp [255.0 kW] @ 5400 rpm, 373 lb-ft of torque [503.6 N-m] @ 4400 rpm) (Includes external oil cooler. Reference the Engine/Axle page for availability.)
Transmission, 6-speed automatic, heavy-duty electronically controlled with overdrive and tow/haul mode and internal transmission oil cooler (Reference the Engine/Axle page for availability.)
Rear Axle, 3.73 Ratio (Requires (9N2) 10,050 lbs. (4559 kg) GVWR or (C7N) 12,300 lbs. (5579 kg) GVWR. Reference the Engine/Axle page for availability.)
Body, standard
GVWR, 12,300 lbs. (5579 kg)
Tow/haul mode selector, instrument panel-mounted
Transmission oil cooler, external
Rear wheel drive
Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
Alternator, 150 amps
Frame, ladder-type
Incomplete vehicle certification
Suspension, front independent with coil springs and stabilizer bar
Suspension, rear hypoid drive axle with multi-leaf springs
Steering, power
Brakes, 4-wheel antilock, 4-wheel disc
Fuel tank capacity, mid-frame and approximately 33 gallons (124.9L)
Exhaust, aluminized stainless-steel muffler and tailpipe

EXTERIOR

Wheels, 6 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug painted steel, heavy duty (Only available with (R05) dual rear wheel configuration)
Tires, front LT225/75R16E all-season, blackwall (Requires (C7N) 12,300 lbs. (5579 kg) GVWR and (R05) dual rear wheel configuration. Jack and spare tire equipment bracket are not included.)
Tires, rear LT225/75R16E all-season, blackwall (Requires (C7N) 12,300 lbs. (5579 kg) GVWR and (R05) dual rear wheel configuration. Jack and spare tire equipment bracket are not included.)
Wheel configuration, rear, dual (Not available with (C4M) 9900 lbs. (4490 kg) GVWR, (JFF) 10,100 lbs. (4581 kg) GVWR or (JL4) StabiliTrak.)
Bumper, front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Grille, Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
Flasher, heavy duty light emitting diode (LED)
Glass, Solar-Ray light-tinted, all windows
Mirrors, outside delete
Wipers, front intermittent wet-arm with pulse washers
License plate kit, front

ENTERTAINMENT

Audio system, AM/FM stereo with MP3 player seek-and-scan, digital clock, TheftLock, random select, auxiliary jack and 2 front door speakers (Not available with (YF1) RV Package.)

INTERIOR

Seating arrangement, driver and front passenger highback bucket includes head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal air bag.)
Air conditioning, single-zone manual (Not available with (R6G) air conditioning delete.)
Seats, front bucket with vinyl trim and head restraints includes inboard armrests (Requires (**W) trim. Not available with SEO (ZP0) delete driver and passenger seats. Includes only driver high-back bucket seat with vinyl trim when ordered with (ZX1) driver-only high-back bucket seating arrangement.)
Cup holders, 3 on the engine console cover
Power outlets 2 auxiliary on engine console cover with covers, 12-volt
Power outlet, 120-volt
Floor covering, Black rubberized-vinyl front
Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer and maintenance reminders
Warning tones, headlamp on and key-in-ignition
Oil life monitor
Theft-deterrent system, vehicle, PASS-Key III
Heater and defogger with front and side window defoggers
Headliner, cloth, over driver and passenger
Visors, driver and front passenger, cloth, padded
Assist handles, driver and right-front passenger
Lighting, interior with dome light and door handle-activated switches

SAFETY

Daytime running lamps
Brake/transmission shift interlock for automatic transmissions
Air bags, frontal, driver and right-front passenger (Included with (ZX2) driver and front passenger high-back bucket seats. Not available with (ZX1) driver only high-back bucket seat. Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Air bag deactivation switch, frontal, passenger-side (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
