Details
- Condition
Pre-Owned Clear Title - Engine
6.7L STRAIGHT 6 CYLINDER - Drivetrain
Four Wheel Drive - Interior
gray - VIN #
3C63D3CL6CG157547 - Mileage
157062 - Transmission
Automatic - Exterior Color
gray - Stock #
157547 - Warranty
As-Is
Key Packages & Features
- AUX Audio
Luxury Features
- Air Conditioning
- Climate Control
- Cruise Control
- Heated Mirrors
- Tilt Steering Wheel
Power Equipment
- 12v Power Outlet
- Power Locks
- Power Mirrors
- Power Steering
- Power Windows
Safety Features
- Anti-Lock Brakes
- Child Proof Door Locks
- Driver's Air Bag
- Dynamic Stability Contol
- Intermittent Wipers
- Passenger Air Bag
- Roll Stability Control
- Side Curtain Airbags
- Traction Control System
Audio / Video
- AM/FM
- Aux. Audio Input
- CD Player
- MP3
Interior & Exterior
- Cloth Seats
- Split Front Bench
- Locking Tailgate
- Tow Hooks
Condition Report
- No Known Accidents
- No Known Bodywork
Standard Specs
MECHANICAL
- 6.7L I6 Cummins turbo-diesel engine
- 6-speed manual transmission w/OD
- 3.42 rear axle ratio
- Electronically-controlled throttle
- HD engine cooling
- Manual shift-on-the-fly transfer case
- Anti-spin rear axle differential
- 11.5" rear axle ring gear diameter
- Four wheel drive
- 730-amp maintenance-free battery
- 160-amp alternator
- 6'4" pickup box
- Class IV receiver hitch
- Trailer tow wiring -inc: 4-pin connector
- 7-pin trailer wiring harness
- Tow hooks
- 10100# GVWR
- HD front shock absorbers
- HD rear shock absorbers
- Front stabilizer bar
- Pwr steering
- Pwr 4-wheel anti-lock disc brakes
- Diesel exhaust brake
- Vehicle Name : Ram 3500
- Body Style : Crew Cab Pickup
- Drivetrain : 4-Wheel Drive
- Gross Axle Wt Rating - Front (lbs) : 5500
- Gross Axle Wt Rating - Rear (lbs) : 6200
- Curb Weight - Front (lbs) : 4495
- Curb Weight - Rear (lbs) : 2776
- Gross Vehicle Weight Rating Cap (lbs) : 10100
- Gross Combined Wt Rating (lbs) : 19000
- Dead Weight Hitch - Max Trailer Wt. (lbs) : 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs) : 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs) : 11600
- Wt Distributing Hitch - Max Tongue Wt. (lbs) : 1740
- Engine Order Code : ETJ
- Engine Type : Diesel I6
- Displacement : 6.7L/408
- Fuel System : Direct Injection
- SAE Net Horsepower @ RPM : 350 @ 3000
- SAE Net Torque @ RPM : 650 @ 1500
- Trans Order Code : DEG
- Trans Type : 6
- Trans Description Cont. : Manual
- First Gear Ratio (:1) : 5.94
- Second Gear Ratio (:1) : 3.28
- Third Gear Ratio (:1) : 1.98
- Fourth Gear Ratio (:1) : 1.31
- Fifth Gear Ratio (:1) : 1.00
- Sixth Gear Ratio (:1) : 0.74
- Reverse Ratio (:1) : 5.42
- Clutch Size (in) : 12.5
- Transfer Case Model : NV271
- Transfer Case Gear Ratio (:1), High : 1.00
- Transfer Case Gear Ratio (:1), Low : 2.72
- Cold Cranking Amps @ 0° F (Primary) : 730
- Maximum Alternator Capacity (amps) : 160
- Maximum Alternator Watts : N/A
- Frame Type : Ladder
- Suspension Type - Front : Live Axle
- Suspension Type - Rear : Live axle
- Axle Type - Front : Hypoid
- Axle Type - Rear : Full-Floating
- Axle Capacity - Front (lbs) : 5500
- Axle Capacity - Rear (lbs) : 6010
- Axle Ratio (:1) - Front : 3.42
- Axle Ratio (:1) - Rear : 3.42
- Shock Absorber Diameter - Front (mm) : N/A
- Shock Absorber Diameter - Rear (mm) : N/A
- Steering Type : Pwr Recirculating Ball
- Turning Diameter - Curb to Curb (ft) : 43.9
- Turning Diameter - Wall to Wall (ft) : N/A
- Brake Type : Pwr
- Brake ABS System : 4-Wheel
- Disc - Front (Yes or ) : Yes
- Disc - Rear (Yes or ) : Yes
- Front Brake Rotor Diam x Thickness (in) : 14.17 x 1.54
- Rear Brake Rotor Diam x Thickness (in) : 14.09 x 1.34
EXTERIOR
- 17" x 7.5" styled steel wheels
- LT265/70R17E all-season OWL tires
- Single rear wheels
- Center wheel hubs
- 17" Steel spare wheel
- Full-size spare tire
- Winch-type spare tire carrier
- Black front bumper
- Black rear bumper
- Front air dam
- Black grille
- Body-color headlamp filler panel
- Auto headlamps
- Quad headlamps
- Cargo lamp
- Black pwr trailer tow mirrors -inc: supplemental signals, courtesy lamps, heated glass
- Tinted glass windows
- Variable-speed intermittent windshield wipers
- Front license plate bracket
- Locking tailgate
- Black door handles
- Front Tire Order Code : TT3
- Rear Tire Order Code : TT3
- Spare Tire Order Code : TBB
- Front Tire Size : LT265/70R17E
- Rear Tire Size : LT265/70R17E
- Spare Tire Size : LT265/70R17E
- Front Tire Capacity (lbs) : 3195
- Rear Tire Capacity (lbs) : 3195
- Spare Tire Capacity (lbs) : 3195
- Revolutions/Mile @ 45 mph - Front : 657
- Revolutions/Mile @ 45 mph - Rear : 657
- Revolutions/Mile @ 45 mph - Spare : 657
- Front Wheel Size (in) : 17 x 7.5
- Rear Wheel Size (in) : 17 x 7.5
- Spare Wheel Size (in) : 17 x 7.5
- Front Wheel Material : Steel
- Rear Wheel Material : Steel
- Spare Wheel Material : Steel
- Wheelbase (in) : 148.9
- Length, Overall w/o rear bumper (in) : 237.4
- Width, Max w/o mirrors (in) : 79.1
- Height, Overall (in) : 78.4
- Overhang, Front (in) : 39.9
- Overhang, Rear w/o bumper (in) : 48.7
- Front Bumper to Back of Cab (in) : 152.0
- Cab to Axle (in) : 36.7
- Ground to Top of Load Floor (in) : 38.9
- Ground Clearance, Front (in) : 8.1
- Ground Clearance, Rear (in) : 7.7
- Cargo Box Length @ Floor (in) : 76.3
- Cargo Box Width @ Floor (in) : 66.4
- Cargo Box Width @ Wheelhousings (in) : 51.0
- Cargo Box (Area) Height (in) : 20.1
- Tailgate Width (in) : 60.4
- Cargo Volume (ft³) : 57.5
ENTERTAINMENT
- Uconnect 130 -inc: AM/FM stereo w/CD/MP3 player
- Audio input jack
- (6) speakers
- Fixed long mast antenna
INTERIOR
- HD vinyl 40/20/40 split-bench seat
- Rear folding bench seat
- Black vinyl floor covering
- MINI FLOOR CONSOLE
- Tilt steering column
- Sentry key theft-deterrent system
- Instrument cluster w/display screen
- Vehicle info center
- 120-MPH primary speedometer
- Pwr windows w/front one-touch up/down
- Pwr accessory delay
- Pwr locks
- Speed control
- Air conditioning
- 12V auxiliary pwr outlet
- Driver/passenger assist handles
- Rear dome lamp
- Black instrument panel bezel
- Rear underseat compartment storage
- 2nd row in-floor storage bins
- Passenger Capacity : 6
- Total Cooling System Capacity (qts) : 29.5
- Front Head Room (in) : 41.0
- Front Leg Room (in) : 41.0
- Front Shoulder Room (in) : 66.0
- Front Hip Room (in) : 63.2
- Second Head Room (in) : 39.9
- Second Leg Room (in) : 40.3
- Second Shoulder Room (in) : 65.7
- Second Hip Room (in) : 63.2
SAFETY
- Electronic stability control
- Advanced multistage front airbags
- Supplemental side airbags
- Supplemental front seat side airbags
- Child safety door locks
- Front/rear side curtain airbags
- Front height-adjustable shoulder belts
- Dual-note horn
EPA Fuel Economy & Specification
- Fifth Wheel Hitch - Max Trailer Wt. (lbs) : - TBD -
- Fifth Wheel Hitch - Max Tongue Wt. (lbs) : - TBD -
- Spring Capacity - Front (lbs) : - TBD -
- Spring Capacity - Rear (lbs) : - TBD -
- Stabilizer Bar Diameter - Front (in) : - TBD -
- Steering Ratio (:1), On Center : - TBD -
- Steering Ratio (:1), At Lock : - TBD -
- Fuel Tank Capacity, Approx (gal) : 34.0
- Fuel Tank Location : Inboard Frame Rails
- Cab to End of Frame (in) : - TBD -
- Ground to Top of Frame (in) : - TBD -
- Frame Width, Rear (in) : - TBD -
- Cargo Box Width @ Top, Rear (in) : - TBD -
- Ext'd Cab Cargo Volume (ft³) : - TBD -
