Details
- Condition
Pre-Owned Clear Title - Engine
4.8L 8 CYLINDER - Drivetrain
Rear Wheel Drive - Interior
Medium Dark Pewter - VIN #
1GCGG25V261197248 - Mileage
103617 - Transmission
Automatic - Exterior Color
Summit White - Stock #
197248 - Warranty
Limited
Luxury Features
- Air Conditioning
Power Equipment
- 12v Power Outlet
- Power Steering
Safety Features
- Driver's Air Bag
- Intermittent Wipers
- Passenger Air Bag
Audio / Video
- AM/FM
Interior & Exterior
- Cloth Seats
- Cup Holders
Condition Report
- No Known Accidents
- No Known Bodywork
Standard Specs
MECHANICAL
- Vehicle Name : Chevrolet Express Cargo Van
- Body Style : 2500 Cargo Van 135" WB
- Body Code : ZW9
- Drivetrain : Rear Wheel Drive
- Gross Axle Wt Rating - Front (lbs) : 4100
- Gross Axle Wt Rating - Rear (lbs) : 5360
- Curb Weight - Front (lbs) : 2923
- Curb Weight - Rear (lbs) : 2296
- Gross Vehicle Weight Rating Cap (lbs) : 8600
- Gross Combined Wt Rating (lbs) : 12000
- Dead Weight Hitch - Max Trailer Wt. (lbs) : 4000
- Dead Weight Hitch - Max Tongue Wt. (lbs) : 400
- Wt Distributing Hitch - Max Trailer Wt. (lbs) : 6300
- Wt Distributing Hitch - Max Tongue Wt. (lbs) : 945
- Engine Order Code : LR4
- Engine Type : Gas V8
- Displacement : 4.8L/293
- Fuel System : SFI
- SAE Net Horsepower @ RPM : 285 @ 5200
- SAE Net Torque @ RPM : 295 @ 4000
- Trans Order Code : MT1
- Trans Type : 4
- Trans Description Cont. : HD Automatic w/OD
- First Gear Ratio (:1) : 2.48
- Second Gear Ratio (:1) : 1.48
- Third Gear Ratio (:1) : 1.00
- Fourth Gear Ratio (:1) : 0.75
- Reverse Ratio (:1) : 2.08
- Cold Cranking Amps @ 0° F (Primary) : 600
- Maximum Alternator Capacity (amps) : 105
- Engine Oil Cooler : Yes
- Frame Type : Ladder
- Suspension Type - Front : Independent Coil
- Suspension Type - Rear : Hypoid Multi-Leaf
- Spring Capacity - Front (lbs) : 4100
- Spring Capacity - Rear (lbs) : 5360
- Axle Type - Front : Independent
- Axle Type - Rear : Semi-Floating
- Axle Capacity - Front (lbs) : 4100
- Axle Capacity - Rear (lbs) : 5360
- Axle Ratio (:1) - Rear : 3.73
- Stabilizer Bar Diameter - Front (in) : 1.38
- Steering Type : Pwr-assisted
- Steering Ratio (:1), On Center : 17.2
- Turning Diameter - Curb to Curb (ft) : 49.2
- Brake Type : Pwr
- Brake ABS System : 4-Wheel
- Disc - Front (Yes or ) : Yes
- Disc - Rear (Yes or ) : Yes
- Front Brake Rotor Diam x Thickness (in) : 12.8 x 1.5
- Rear Brake Rotor Diam x Thickness (in) : 13 x 1.1
- Rear Door Type : Dual Swing-out
INTERIOR
- Passenger Capacity : 2
- Total Cooling System Capacity (qts) : 13.6
- Front Head Room (in) : 40.2
- Front Leg Room (in) : 41.3
- Front Shoulder Room (in) : 68.8
- Front Hip Room (in) : 65.5
EPA Fuel Economy & Specification
- Maximum Alternator Watts : - TBD -
- Shock Absorber Diameter - Front (mm) : - TBD -
- Shock Absorber Diameter - Rear (mm) : - TBD -
- Spare Tire Capacity (lbs) : -TBD-
- Revolutions/Mile @ 45 mph - Front : - TBD -
- Revolutions/Mile @ 45 mph - Rear : - TBD -
- Revolutions/Mile @ 45 mph - Spare : - TBD -
- Front Wheel Size (in) : 16 x - TBD -
- Rear Wheel Size (in) : 16 x - TBD -
- Spare Wheel Size (in) : 16 x - TBD -
- Steering Ratio (:1), At Lock : - TBD -
- Turning Diameter - Wall to Wall (ft) : - TBD -
- Fuel Tank Capacity, Approx (gal) : 31
- Fuel Tank Location : LH Midship Inboard
- Overhang, Front (in) : - TBD -
- Overhang, Rear w/bumper (in) : - TBD -
- Cargo Area Width @ Beltline (in) : - TBD -
EXTERIOR
- Front Tire Order Code : XHH
- Rear Tire Order Code : YHH
- Spare Tire Order Code : ZHH
- Front Tire Size : LT245/75R16E
- Rear Tire Size : LT245/75R16E
- Spare Tire Size : LT245/75R16E
- Front Tire Capacity (lbs) : 2060
- Rear Tire Capacity (lbs) : 2680
- Front Wheel Material : Steel
- Rear Wheel Material : Steel
- Spare Wheel Material : Steel
- Wheelbase (in) : 135
- Length, Overall w/rear bumper (in) : 224.1
- Width, Max w/o mirrors (in) : 79.4
- Height, Overall (in) : 81.6
- Ground to Top of Load Floor (in) : 27.7
- Ground Clearance, Front (in) : 8.6
- Ground Clearance, Rear (in) : 7.6
- Rear Door Opening Height (in) : 49.4
- Rear Door Opening Width (in) : 57.0
- Side Door Type : Swing-out
- Side Door Opening Height (in) : 47.9
- Side Door Opening Width (in) : 44.1
- Step Up Height - Front (in) : 20.1
- Step Up Height - Side (in) : 20.9
- Cargo Area Length @ Floor to Console (in) : 153.6
- Cargo Area Length @ Floor to Seat 1 (in) : 127.8
- Cargo Box Width @ Wheelhousings (in) : 52.7
- Cargo Box (Area) Height (in) : 51.9
- Cargo Volume (ft³) : 225.1
