Details
- Condition
Pre-Owned Clear Title - Engine
6.8L 10 CYLINDER - Drivetrain
Four Wheel Drive - Interior
gray - VIN #
1FTNW21S12EC97740 - Mileage
211229 - Transmission
Automatic - Exterior Color
white - Stock #
C97740 - Warranty
As-Is
Power Equipment
- Power Locks
- Power Steering
Safety Features
- Driver's Air Bag
- Intermittent Wipers
- Passenger Air Bag
Audio / Video
- AM/FM
Interior & Exterior
- Clock
- Full Leather Interior Surface
- Tachometer
- Vanity Mirrors
- Tow Hooks
Condition Report
- No Known Accidents
- No Known Bodywork
Standard Specs
MECHANICAL
- 5.4L (330) SOHC SEFI V8 engine
- 6-speed manual transmission w/OD
- 2-speed transfer case
- 3.73 axle ratio
- Four wheel drive
- Manual locking front hubs
- 78 amp/hr (750 CCA) maintenance-free battery
- 130 amp alternator
- Trailer tow pkg-inc: 7-wire harness, trailer brake wiring kit, trailer tow guide
- 172" WB
- 8' pickup box w/tie-down hooks & partitionable/stackable storage
- (2) Front tow hooks
- 8,800# GVWR (4700 front/6084 rear), springs (4700 front/6084 rear), axles (5200 front/6084 rear)
- Mono-beam front axle
- Front stabilizer bar
- Auxiliary rear springs *Activated when carrying heavy loads*
- HD gas shock absorbers
- (5) LT235/85R16E all-season SBR BSW tires
- (4) 16" x 7.0" chrome steel wheels
- Full-size spare tire w/steel wheel, lock, underframe crank carrier
- Pwr steering
- Pwr 4-wheel disc brakes w/4-wheel anti-lock system
- 38 gallon fuel tank
- Vehicle Name : Ford Super Duty F-250
- Body Style : Crew Cab 8'
- Body Code : 172" WB
- Drivetrain : 4-Wheel Drive
- Gross Axle Wt Rating - Front (lbs) : 4400
- Gross Axle Wt Rating - Rear (lbs) : 6084
- Curb Weight - Front (lbs) : 3637
- Curb Weight - Rear (lbs) : 2518
- Gross Vehicle Weight Rating Cap (lbs) : 8800
- Gross Combined Wt Rating (lbs) : 13,500
- Dead Weight Hitch - Max Trailer Wt. (lbs) : 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs) : 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs) : 12500
- Wt Distributing Hitch - Max Tongue Wt. (lbs) : 1250
- Fifth Wheel Hitch - Max Trailer Wt. (lbs) : 14000
- Fifth Wheel Hitch - Max Tongue Wt. (lbs) : 3500
- Engine Order Code : 99L
- Engine Type : Gas V8
- Displacement : 5.4L/330
- Fuel System : SEFI
- SAE Net Horsepower @ RPM : 260 @ 4500
- SAE Net Torque @ RPM : 350 @ 2500
- Trans Order Code : 445
- Trans Type : 6
- Trans Description Cont. : HD Manual w/OD
- First Gear Ratio (:1) : 5.79
- Second Gear Ratio (:1) : 3.30
- Third Gear Ratio (:1) : 2.10
- Fourth Gear Ratio (:1) : 1.30
- Fifth Gear Ratio (:1) : 1.00
- Sixth Gear Ratio (:1) : 0.72
- Reverse Ratio (:1) : 5.23
- Clutch Size (in) : 11.9
- Trans Power Take Off : SAE 6-Bolt
- Trans PTO Access : LH & RH
- Transfer Case Model : New Venture 271
- Transfer Case Gear Ratio (:1), High : 1.00
- Transfer Case Gear Ratio (:1), Low : 2.72
- Cold Cranking Amps @ 0° F (Primary) : 750
- Maximum Alternator Capacity (amps) : 130
- Frame Type : Ladder-Type
- Suspension Type - Front : Single Leaf
- Suspension Type - Rear : Multi-leaf
- Spring Capacity - Front (lbs) : 4400
- Spring Capacity - Rear (lbs) : 6830
- Axle Type - Front : Dana Monobeam
- Axle Type - Rear : Ford Full-Floating
- Axle Capacity - Front (lbs) : 5200
- Axle Capacity - Rear (lbs) : 6830
- Axle Ratio (:1) - Front : 3.73
- Axle Ratio (:1) - Rear : 3.73
- Shock Absorber Diameter - Front (mm) : 35
- Shock Absorber Diameter - Rear (mm) : 35
- Steering Type : Power
- Steering Ratio (:1), On Center : 17.0
- Turning Diameter - Curb to Curb (ft) : 61.6
- Turning Diameter - Wall to Wall (ft) : 64.2
- Brake Type : Power
- Brake ABS System : 4-Wheel
- Disc - Front (Yes or ) : Yes
- Disc - Rear (Yes or ) : Yes
EXTERIOR
- Front/rear license plate bracket
- Chrome front bumper w/lower center trim
- Chrome rear step bumper
- Color-keyed body-side moldings
- Argent box-rail/tailgate moldings
- Valance air dam
- Argent grille w/chrome surround
- Single beam jewel effect headlamps
- Fog lamps
- Pickup box/cargo light
- Black fold-away pwr mirrors
- Solar tinted glass
- Interval wipers
- Black door handles
- Removable locking tailgate w/black handle
- Front Tire Order Code : T35
- Rear Tire Order Code : T35
- Front Tire Size : LT235/85R16E
- Rear Tire Size : LT235/85R16E
- Spare Tire Size : LT235/85R16E
- Front Tire Capacity (lbs) : 3042
- Rear Tire Capacity (lbs) : 3042
- Spare Tire Capacity (lbs) : 3042
- Revolutions/Mile @ 45 mph - Front : 655
- Revolutions/Mile @ 45 mph - Rear : 655
- Revolutions/Mile @ 45 mph - Spare : 655
- Front Wheel Size (in) : 16 x 7.0
- Rear Wheel Size (in) : 16 x 7.0
- Spare Wheel Size (in) : 16 x 7.0
- Front Wheel Material : Chrome
- Rear Wheel Material : Chrome
- Spare Wheel Material : Steel
- Wheelbase (in) : 172.4
- Length, Overall w/o rear bumper (in) : 257.6
- Width, Max w/o mirrors (in) : 79.9
- Height, Overall (in) : 80.8
- Overhang, Front (in) : 37.4
- Overhang, Rear w/o bumper (in) : 47.8
- Front Bumper to Back of Cab (in) : 153.6
- Cab to Axle (in) : 56.2
- Ground to Top of Load Floor (in) : 37.0
- Cargo Box Length @ Floor (in) : 98.6
- Cargo Box Width @ Top, Rear (in) : 64.6
- Cargo Box Width @ Wheelhousings (in) : 50.9
- Cargo Box (Area) Height (in) : 20.0
- Tailgate Width (in) : 65.0
- Cargo Volume (ft³) : 77.7
INTERIOR
- High series cloth 40/20/40 split front bench seat-inc: armrest, cup holders, storage, outboard headrests
- Driver & front passenger manual lumbar support
- Forward-folding rear flight bench seat
- Color-keyed carpet full-floor covering
- Front/rear color-keyed carpeted floor mats
- Color-keyed scuff plates
- Black vinyl steering wheel
- Tilt steering column
- Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges, indicator lights
- Belt Minder seatbelt-not-buckled chime & flashing warning light
- Pwr windows w/driver one-touch-down/backlit switches
- Pwr door locks w/backlit switches
- Accessory delay
- Speed control
- Inside hood release
- Air conditioning
- (4) air registers w/positive shut-off
- Premium electronic AM/FM stereo radio w/cassette, single CD player-inc: digital clock, premium sound w/amplifier, (4) speakers
- Color-keyed instrument panel w/dual cupholders/glove box/ashtray/cigar lighter
- Auxiliary pwr point
- Color-keyed molded door trim panel-inc: soft armrest, grab handle,reflector, upper vinyl insert, carpeted map pocket
- 11.5" day/night mirror
- Color-keyed molded cloth headliner
- Front passenger grab handle
- Grab handles mounted over rear doors
- Front passenger-side roof ride handle
- Rear seating roof ride handles
- Dual color-keyed cloth sunvisors-inc: driver-side map strap, passenger-side mirror insert
- Dual color-keyed coat hooks
- Dual dome lamps w/time delay off
- Dual map lights
- Underhood service light
- Grey fabric back panel cover
- Passenger Capacity : 6
- Total Cooling System Capacity (qts) : 26.0
- Front Head Room (in) : 41.4
- Front Leg Room (in) : 40.7
- Front Shoulder Room (in) : 68.0
- Front Hip Room (in) : 67.4
- Second Head Room (in) : 41.0
- Second Leg Room (in) : 42.5
- Second Shoulder Room (in) : 68.0
- Second Hip Room (in) : 67.3
SAFETY
- Rear wheel anti-lock braking system
- Driver & front passenger airbags
- Color-keyed safety belts w/front seat adjustable D-rings
- Front/rear child seat tethers (on all seats)
- Dual-note horn
EPA Fuel Economy & Specification
- Engine Oil Cooler : - TBD -
- Stabilizer Bar Diameter - Front (in) : - TBD -
- Steering Ratio (:1), At Lock : - TBD -
- Front Brake Rotor Diam x Thickness (in) : 13.03 x - TBD -
- Rear Brake Rotor Diam x Thickness (in) : 12.83 x - TBD -
- Fuel Tank Capacity, Approx (gal) : 38
- Fuel Tank Location : Midship
- Cab to End of Frame (in) : - TBD -
- Ground to Top of Frame (in) : - TBD -
- Frame Width, Rear (in) : - TBD -
- Ground Clearance, Front (in) : - TBD -
- Ground Clearance, Rear (in) : - TBD -
- Cargo Box Width @ Floor (in) : - TBD -
