Details
- Condition
Pre-Owned Clear Title - Engine
6.8L 10 CYLINDER - Drivetrain
Four Wheel Drive - Interior
Medium Parchment - VIN #
1FMNU43S1YEA46753 - Mileage
163889 - Transmission
Automatic - Exterior Color
Oxford White - Stock #
A46753 - Warranty
Key Packages & Features
- Reverse Camera
- Security System
- Keyless Entry
- Parking Sensors
Luxury Features
- Air Conditioning
- Cruise Control
- Heated Mirrors
- Leather Steering Wheel
- Rear A/C
- Rear Radio Control
- Tilt Steering Wheel
- Tinted Windows
- Wood Trim
Power Equipment
- Power Driver's Seat
- Power Mirrors
- Power Steering
Safety Features
- Child Proof Door Locks
- Driver's Air Bag
- Keyless Entry
- Parking Sensors
- Passenger Air Bag
- Rear Defogger
- Security System
Audio / Video
- AM/FM
- Anti-Theft
- Cassette
- CD Player
- Reverse Camera
Interior & Exterior
- Carpeted Floor Mats
- Overhead Console
- Tachometer
- Third Seat
- Vanity Mirrors
- Body Side Moldings
- Exterior Keypad Entry
- Rear Wipers
- Roof Rack
- Running Boards
- Tow Hooks
Condition Report
- No Known Accidents
- No Known Bodywork
Standard Specs
MECHANICAL
- 6.8L (415) SOHC SEFI V10 engine
- 4-speed electronically-controlled automatic transmission w/OD
- 2-speed transfer case w/Control Trac Shift-on-the-Fly
- 3.73 axle ratio
- Four wheel drive
- 78 amp/hr (750 CCA) battery
- Battery saver
- 130 amp alternator
- Class IV trailer towing pkg-inc: 7-wire harness, trailer brake wiring kit
- (2) Front tow hooks
- 8,900# GVWR (3800 front/5240 rear), springs (3800 front/5240 rear), axles (5200 front/7000 rear)
- Front stabilizer bar
- (5) LT265/75R16D all-season SBR OWL tires
- (4) 16" x 7.0" 5-hole styled aluminum wheels
- Full size spare tire
- Pwr steering
- Pwr 4-wheel disc brakes
- 4-wheel anti-lock braking system
- 44 gallon fuel tank
- Vehicle Name : Ford Excursion
- Body Style : 4 Door
- Body Code : 137" WB
- Drivetrain : 4-Wheel Drive
- Gross Axle Wt Rating - Front (lbs) : 4700
- Gross Axle Wt Rating - Rear (lbs) : 5250
- Curb Weight - Front (lbs) : 3575
- Curb Weight - Rear (lbs) : 3615
- Gross Vehicle Weight Rating Cap (lbs) : 8900
- Gross Combined Wt Rating (lbs) : 17000
- Dead Weight Hitch - Max Trailer Wt. (lbs) : 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs) : 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs) : 10000
- Wt Distributing Hitch - Max Tongue Wt. (lbs) : 1000
- Engine Order Code : 99S
- Engine Type : Gas V10
- Displacement : 6.8/415
- Fuel System : SEFI
- SAE Net Horsepower @ RPM : 310 @ 4250
- SAE Net Torque @ RPM : 425 @ 3250
- Trans Order Code : 44E
- Trans Type : 4
- Trans Description Cont. : Automatic w/OD,
- Trans Description Cont. Again : Electronic
- First Gear Ratio (:1) : 2.71
- Second Gear Ratio (:1) : 1.54
- Third Gear Ratio (:1) : 1.00
- Fourth Gear Ratio (:1) : 0.71
- Reverse Ratio (:1) : 2.18
- Transfer Case Model : Warner 4406
- Transfer Case Gear Ratio (:1), High : 1.00
- Transfer Case Gear Ratio (:1), Low : 2.72
- Cold Cranking Amps @ 0° F (Primary) : 750
- Maximum Alternator Capacity (amps) : 130
- Engine Oil Cooler : Yes
- Frame Type : Boxed w/Single Channel
- Suspension Type - Front : Single-Stage Leaf
- Suspension Type - Rear : Multi-Stage Leaf
- Spring Capacity - Front (lbs) : 4100
- Spring Capacity - Rear (lbs) : 5250
- Axle Type - Front : Dana 50 Monobeam
- Axle Type - Rear : Full-Floating
- Axle Capacity - Front (lbs) : 5200
- Axle Capacity - Rear (lbs) : 6830
- Axle Ratio (:1) - Front : 3.73
- Axle Ratio (:1) - Rear : 3.73
- Shock Absorber Diameter - Front (mm) : 1.375
- Shock Absorber Diameter - Rear (mm) : 1.375
- Stabilizer Bar Diameter - Front (in) : 1.42
- Steering Type : Power
- Steering Ratio (:1), On Center : 17
- Turning Diameter - Curb to Curb (ft) : 50.4
- Turning Diameter - Wall to Wall (ft) : 53.0
- Brake Type : Power
- Brake ABS System : 4-Wheel
- Disc - Front (Yes or ) : Yes
- Disc - Rear (Yes or ) : Yes
- Rear Door Type : Tri-Panel
EXTERIOR
- Body-side paint stripe
- Luggage rack
- Chrome front bumper
- Beige rear step bumper
- Beige body-side/wheellip moldings
- Argent grille
- Illuminated beige running boards
- "Blocker Beam" front bumper supplement
- Aero halogen headlights
- Black pwr heated mirrors
- Privacy glass
- Pwr rear quarter windows
- Speed-sensitive intermittent windshield wipers
- Rear window intermittent wiper w/washer
- Color-keyed door handles
- Reverse sensing system
- Tri-panel rear door-inc: top half liftgate, 2 lower swing-out cargo doors
- Front Tire Order Code : T48
- Rear Tire Order Code : T48
- Spare Tire Order Code : T48
- Front Tire Size : LT265/75R16D
- Rear Tire Size : LT265/75R16D
- Spare Tire Size : LT265/75R16D
- Front Tire Capacity (lbs) : 3000
- Rear Tire Capacity (lbs) : 3000
- Spare Tire Capacity (lbs) : 3000
- Revolutions/Mile @ 45 mph - Front : 658
- Revolutions/Mile @ 45 mph - Rear : 658
- Front Wheel Size (in) : 16 x 7.0
- Rear Wheel Size (in) : 16 x 7.0
- Front Wheel Material : Aluminum
- Rear Wheel Material : Aluminum
- Spare Wheel Material : Steel
- Wheelbase (in) : 137.0
- Length, Overall w/rear bumper (in) : 226.7
- Width, Max w/o mirrors (in) : 80.0
- Height, Overall (in) : 79.5
- Overhang, Front (in) : 37.4
- Overhang, Rear w/bumper (in) : 52.3
- Ground Clearance, Front (in) : 8.5
- Ground Clearance, Rear (in) : 8.5
- Rear Door Opening Height (in) : 38.1
- Rear Door Opening Width (in) : 55.8
- Cargo Area Length @ Floor to Seat 1 (in) : 165.0
- Cargo Area Length @ Floor to Seat 2 (in) : 108.3
- Cargo Area Length @ Floor to Seat 3 (in) : 48.6
- Cargo Box Width @ Wheelhousings (in) : 52.5
- Cargo Volume to Seat 1 (ft³) : 146.4
- Cargo Volume to Seat 2 (ft³) : 100.7
- Cargo Volume to Seat 3 (ft³) : 48.6
INTERIOR
- Leather front captains chairs-inc: 6-way pwr driver seat
- Leather 2nd row reclining 60/40 split bench seat-inc: dual tip/slide feature center armrests, cup holders
- Leather 3rd row 3-passenger removable fold-flat bench seat w/rollers
- Floor console w/storage bin
- Color-keyed 12 oz carpet
- 1st/2nd color-keyed carpeted floor mats
- Leather steering wheel
- Tilt steering column
- Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges
- Speed control
- Pwr windows w/driver one-touch-down
- Pwr door locks
- Remote keyless entry-inc: 2-transmitters, door keypad
- Passive anti-theft system
- Manual front/rear air conditioning
- Rear floor heat ducts
- Rear window defroster
- Premium electronic AM/FM stereo w/compact disc/cassette-inc: 80-watt amp
- Rear seat audio controls
- Glove box
- (10) cup holders
- Cigarette lighter
- Color-keyed instrument panel
- (5) auxiliary pwr points
- Molded door trim panel-inc: soft armrest, upper woodgrain insert, dual map pockets, lower carpet
- Electrochromatic rear view mirror
- Overhead console-inc: trip computer, pwr rear quarter window controls
- Molded cloth headliner
- Front/rear assist handles
- Color-keyed sun visors-inc: illuminated vanity mirrors, secondary sun blade
- Dual coat hooks over 2nd row doors
- Dual coat hooks in cargo area
- Lights-inc: underhood, glove box, front dome/map, front door courtesy, overhead rear cargo, 2nd/3rd row map lights
- Cargo net
- Passenger Capacity : 8
- Total Cooling System Capacity (qts) : 28.5
- Front Head Room (in) : 41.0
- Front Leg Room (in) : 42.3
- Front Shoulder Room (in) : 68.3
- Front Hip Room (in) : 67.5
- Second Head Room (in) : 41.1
- Second Leg Room (in) : 40.5
- Second Shoulder Room (in) : 67.0
- Second Hip Room (in) : 66.9
- Third Head Room (in) : 38.6
- Third Leg Room (in) : 39.0
- Third Shoulder Room (in) : 64.9
- Third Hip Room (in) : 52.5
SAFETY
- Driver & front passenger airbags
- 4-wheel anti-lock braking system
- 1st/2nd row color-keyed safety belts w/adjustable D-rings
- Child-proof rear door locks
- "Blocker Beam" front bumper supplement
EPA Fuel Economy & Specification
- Revolutions/Mile @ 45 mph - Spare : - TBD -
- Spare Wheel Size (in) : - TBD -
- Front Brake Rotor Diam x Thickness (in) : 12.1 x - TBD -
- Rear Brake Rotor Diam x Thickness (in) : 13.2 x - TBD -
- Fuel Tank Capacity, Approx (gal) : 44
- Fuel Tank Location : Midship
- Ground to Top of Load Floor (in) : - TBD -
- Step Up Height - Front (in) : - TBD -
- Step Up Height - Side (in) : - TBD -
- Cargo Area Width @ Beltline (in) : - TBD -
- Cargo Box (Area) Height (in) : - TBD -
